Flexible embellishment module for upgrading existing or new machines with digital embellishment solutions
Digital varnishing or digital metallization - easy and flexible to integrate whenever and wherever you want
The DM-Flexliner 3D is designed to be a flexible and easy to integrate OEM digital embellishment module.
With the DM-Flexliner 3D, you have the opportunity to enhance your narrow-web machine platforms with a range of digital embellishment processes. Whether it's on narrow-web flexo, offset, or digital printing machines, or narrow-web converting machines, the DM-Flexliner 3D offers versatile options. You can retrofit the DM-Flexliner 3D to existing machines or use it as a pre-integrated OEM digital embellishment module on new machines.
Flexible integration of digital embellishment with the DM-Flexliner 3D on narrow-web machines.
Modular. Industrial.
The DM-Flexliner 3D gives you flexibility and freedom of application: You can digitally varnish or, if configured, digitally metallize. Thanks to the "inkjet on substrate" technology, the module offers individual flexibility for your embellishment process and enables you to achieve flat and haptic effects from 4 to 100 μm.
The DM-Flexliner 3D offers impressive quality in digital metallization or digital varnishing with excellent surfaces and filigree structures, suitable for thin and thick layers.
Assets of the DM-Flexliner 3D
The OEM module for digital flat or raised varnishing or metallization effects is ready to use in your printing or converting process.
Video
See our DM-Flexliner 3D module at Labelexpo Europe. It is the perfect complement to the Gallus Labelfire press.
Technical data
| Substrate | |||
|---|---|---|---|
| Web width | max. 440 mm | ||
| Substrate thickness | max. 0.7 mm | ||
| Print system | |||
| Inkjet system: | Drop on Demand, Single Pass | ||
| Native resolution: | 600 dpi | ||
| Vanish lay down ²)³): | 2 - 100 g/m² | ||
| Print speed ¹): | 10 - 60 m/min | ||
| Register accuracy: | +/- 0.15 mm | ||
| Image format: | |||
| Data transfer: | USB, Hotfolder | ||
| Dimension / Weight | |||
| Dimension (LxHxW): | 800 x 800 x 1600 mm | ||
| Modul net weight: | tbd | ||
1) = depending on varnish lay down and substrate type
2) = Depending on working speed
3) = Depending on varnish type and surface tension
All technical data represent approximation values. Steinemann DPE reserves the right to make mechanical and design modifications.
.
Narrow web
Labels not only inform, they convince. Digital finishing can make the difference - even for short and medium run lengths.
Steinemann DPE single source
system solutions
Steinemann DPE, together with Leonhard KURZ, offers outstanding, high-quality system solutions for industrial, digital metallization and digital varnishing.
From the machine to the transfer metallization to the ink, we offer you all components from a single source – perfectly matched to each other.
Consumables
To achieve the best possible results, you need to use the right consumables that are optimized for your machine and your needs.
We will be happy to guide you.
Spares
Wear and tear is inevitable when machines are used intensively.
We provide replacements.
Sustainability
Sustainable production with digital print embellishment?
Learn how sustainable print enhancement is possible with Steinemann DPE systems.
